Supports customization with a processing capacity of up to 15900 CFM (cubic feet per minute).
The 200 CFM refrigerated air dryer (air cooled) is a compact and efficient solution for removing moisture from compressed air systems. Designed for mid-sized industrial applications, this dryer ensures clean, dry air to protect downstream equipment from corrosion, contamination, and failure.
With air-cooled technology and stable dew point performance, the 200 CFM refrigerated air dryer (air cooled) offers a reliable and energy-saving approach to compressed air drying.
✅ Rated for 200 CFM: Optimized to handle air flow rates up to 200 CFM, ideal for medium-scale operations.
✅ Air Cooled Condenser: No need for cooling water — suitable for flexible installation in any plant environment.
✅ Stable Dew Point: Maintains a consistent pressure dew point between 2–10°C (35.6–50°F).
✅ Efficient Heat Exchanger: Maximizes moisture separation while minimizing pressure loss.
✅ Energy Efficient: Designed to reduce power consumption with high-performance components.
✅ Automatic Drain System: Prevents water accumulation and extends system life.
✅ Compact Design: Space-saving footprint for easy integration into existing systems.
The 200 CFM refrigerated air dryer (air cooled) combines durability and performance to meet the demands of modern compressed air systems.
Inlet Air Temperature: ≤ 45°C (113°F)
Ambient Temperature: 5 – 45°C (41 – 113°F)
Installation Location: Indoor, clean and well-ventilated environment
Power Supply: 220V / 1Ph / 50Hz (custom options available)
Refrigerant Type: R134a or R410A (environmentally friendly refrigerants)
Filtration Advice: Pre-filters and after-filters recommended for best air quality
| Model | 200 CFM Refrigerated Air Dryer (Air Cooled) |
|---|---|
| Air Capacity | 200 CFM (Cubic Feet per Minute) |
| Cooling Type | Air Cooled |
| Refrigerant | R134a / R410A |
| Max Pressure | 10 bar |
| Pressure Dew Point | 2 – 10°C |
| Power Supply | 220V / 1Ph / 50Hz |
| Connection Size | 1¼” NPT |
| Dimensions (L×W×H) | 850 × 500 × 900 mm |
| Weight | 95 kg |
The 200 CFM refrigerated air dryer (air cooled) is engineered for easy installation, consistent performance, and long service life.
The 200 CFM refrigerated air dryer (air cooled) is ideal for a wide range of industries where moisture-free compressed air is essential:
🏭 Manufacturing – Improve performance and longevity of pneumatic tools and automation systems
🧰 Metalworking & Machining – Prevent rust and moisture in cutting, drilling, and CNC operations
🚗 Automotive Workshops – Maintain clean air for painting, air tools, and tire systems
🍴 Food & Beverage – Ensure hygienic conditions in packaging and processing
📦 General Industrial Use – Reliable air drying for air compressors and distribution systems
– As an air treatment and gas purification manufacturer, we can meet all your compressed air quality and industrial gas needs. This includes various filtering equipment and customized air quality services.
– Our company is always ready to provide explanations. Just share your air quality requirements and we can develop the best system for you.
Need help navigating our compressed air dryer offer? We are always ready to put together the solution that best meets your needs.
The 100 CFM refrigerated air dryer (air cooled) is a high-performance compressed air treatment solution designed to remove moisture from compressed air systems efficiently. Ideal for small to medium-sized industrial applications, this air dryer ensures clean, dry air to protect downstream equipment and improve productivity.
With advanced air-cooling technology, compact design, and energy-efficient components, the 100 CFM refrigerated air dryer (air cooled) is the perfect choice for users seeking reliability, efficiency, and long service life.
The air is pure, no secondary pollution, integrated skid-mounted design, compact structure, stable dew point, remarkable water removal effect.
Stainless steel plate heat exchanger with high heat exchange efficiency and compact structure.
Independent stainless steel steam-water separator with high water separation efficiency, timely separates condensed water and other impurities from compressed air and discharges them out of the machine.
The whole machine is made of stainless steel or aluminum alloy, which will not rust and prevent secondary contamination of compressed air.
Single chip intelligent control, real-time display of evaporation temperature, including over-temperature alarm, electrical fault, high pressure alarm, low pressure alarm and other functions.
Low energy consumption: the three-in-one plate heat exchanger is adopted, and the whole machine can save 20~30% of energy consumption;
Low pressure drop: the pressure loss of the whole machine is less than 0.015MPa, which is lower than the national standard;
Low dew point: under standard working conditions, the pressure dew point is as low as 2~10℃, and the electronic bypass valve is adopted, making the system more stable;
Environmentally friendly and durable: the whole series adopts environmentally friendly refrigerant R410a/R407C, which meets international environmental standards and has a maximum pressure of 1.6MPa;
Good treatment effect: equipped with an independent water distribution system and it is a multiple upgraded version, the water distribution efficiency is guaranteed;
Wide application conditions: hydrophilic aluminum foil is used, and the whole series is equipped with heat exchangers and pre-coolers as standard, which can better adapt to harsh working conditions
Wide application conditions: hydrophilic aluminum foil is used, and the whole series is equipped with heat exchangers and pre-coolers as standard, which can better adapt to harsh working conditions
Customized according to needs: color can be customized, PLC is optional, dry contacts, Modbus communication, Internet of Things communication, etc. can be customized according to customer needs
